Standard series Liquid Cold Plate

Standard Series Liquid Cold Plate

The Standard Series Liquid Cold Plates are designed to fit general cooling needs.
Can be used in a wide range of fields with a shorter lead time of 1 week, with a wide range of sizes up to 300*300mm.
Best for urgent needs/evaluation/ tests.

HOME > PRODUCTS > Liquid Cold Plates > Standard series Liquid Cold Plate

Want to know the reason why the brazed Liquid Cold Plates can:

  • Reduce more temperature
  • Achieve uniform cooling

Our commitments

The performance of liquid cold plates varies greatly depending on the flow path and the accuracy of the contact surface with the heat source even if the material and pump capacity are the same.

Standard Liquid Cold Plate (Aluminum)

Standard type

Size (mm) Tube (mm) Catalog Number Drawing
100×100×19 12×10 HS-A100 PDF
80×170×19 12×10 HS-A80-170 PDF
120×120×19 12×10 HS-A120 PDF
150×170×19 12×10 HS-A150-170 PDF
170×170×19 12×10 HS-A170 PDF
Universal Liquid Cold Platemore
230×230×22 12×10 HS-UA230 PDF
300×300×22 12×10 HS-UA300 PDF
Semi-Universal Liquid Cold Platemore
80×170×19 12×10 HS-SA80-170 PDF
150×170×19 12×10 HS-SA150-170 PDF

The Standard Series products can be shipped in 1 week after receiving orders.
* Universal/ Semi-Universal series will be shipped in 2 weeks.
Please contact us for more information.

IGBT type

Size (mm) Tap (mm) Tube (mm) Catalog Number Drawing
80×170×19 48×93 12×10 HS-A80-170-P48-93-M6 PDF
80×170×19 48×112 12×10 HS-A80-170-P48-112-M6 PDF
80×170×19 50×110 12×10 HS-A80-170-P50-110-M6 PDF
80×170×19 57×124 12×10 HS-A80-170-P57-124-M6 PDF
80×170×19 62×93 12×10 HS-A80-170-P62-93-M6 PDF
150×170×19 110×110 12×10 HS-A150-170-P110-110-M6 PDF
150×170×19 78×110 12×10 HS-A150-170-P78-110-M6 PDF
150×170×19 86×127 12×10 HS-A150-170-P86-127-M6 PDF
150×170×19 (57+57)×124 12×10 HS-A150-170-P57×2-124-M6 PDF

IGBT Series can be shipped in 2 weeks after receiving orders.
Please contact us for more information.

Standard Liquid Cold Plate (Copper)

Standard type

Size (mm) Tube (mm) Catalog Number Drawing
60×60×19 12×10 HS-C60 PDF
100×100×19 12×10 HS-C100 PDF
80×170×19 12×10 HS-C80-170 PDF
120×120×19 12×10 HS-C120 PDF
120×210×19 12×10 HS-C120-210 PDF
150×170×19 12×10 HS-C150-170 PDF
170×170×19 12×10 HS-C170 PDF
Liquid Cold Plate [Pipe type]
170×170×12.5 8×6 HS-C170P PDF
Universal Liquid Cold Platemore
230×230×22 12×10 HS-UC230 PDF
300×300×22 12×10 HS-UC300 PDF
Semi-Universal Liquid Cold Platemore
80×170×19 12×10 HS-SC80-170 PDF
150×170×19 12×10 HS-SC150-170 PDF
150×230×19 12×10 HS-SC150-230 PDF
140×300×19 12×10 HS-SC140-300 PDF

The Standard Series products can be shipped in 1 week after receiving orders.
* Universal/ Semi-Universal series will be shipped in 2 weeks.
Please contact us for more information

IGBT type

Size (mm) Tap (mm) Tube (mm) Catalog Number Drawing
80×170×19 48×93 12×10 HS-C80-170-P48-93-M6 PDF
80×170×19 48×112 12×10 HS-C80-170-P48-112-M6 PDF
80×170×19 50×110 12×10 HS-C80-170-P50-110-M6 PDF
80×170×19 57×124 12×10 HS-C80-170-P57-124-M6 PDF
80×170×19 62×93 12×10 HS-C80-170-P62-93-M6 PDF
150×170×19 110×110 12×10 HS-C150-170-P110-110-M6 PDF
150×170×19 78×110 12×10 HS-C150-170-P78-110-M6 PDF
150×170×19 86×127 12×10 HS-C150-170-P86-127-M6 PDF
150×170×19 (57+57)×124 12×10 HS-C150-170-P57×2-124-M6 PDF
150×230×19 (57+57+57)×124 12×10 HS-C150-230-P57×3-124-M6 PDF
140×300×19 (50+50+50+50+50)×124 12×10 HS-C140-300-P50×5-110-M6 PDF

IGBT Series can be shipped in 2 weeks after receiving orders.
Please contact us for more information.

Performance

  • 60×60
  • 100×100
  • 80×170
  • 120×120
  • 120×210
  • 150×170
  • 170×170
  • 150×230
  • 140×300
  • 230×230
  • 300×300

60

100

80-170

120

120-210

150-170

170

150-230

140-300

230

300

Standard Series Liquid Cold Plate -Pipe Connection-
